Code / Development / My Own Stuff / Unity September 25, 2013 @ 12:01

Clamped Bezier Spline for Unity

There are probably a many more of these BSpline implementstions to be found on the interwebs, so here’s another one:

using UnityEngine;

public class BSpline {

    private BSpline() { }

    public static Vector3 GetPoint(Vector3[] cvs, float t) {
        int segCount = cvs.Length - 1;

        float u = t * segCount;
        float v = u % 1;
        int seg = Mathf.FloorToInt(u);

        if (seg >= segCount) {
            v = 1;
            seg = segCount - 1;
        } else if (seg < 0) {
            v = 0;
            seg = 0;
        }

        Vector3 a, b, c ,d;

        if (seg == 0) {
            a = cvs[seg];
            b = cvs[seg];
            c = cvs[seg+1];
            d = cvs[seg+2];
        } else if (seg == segCount - 1) {
            a = cvs[seg-1];
            b = cvs[seg];
            c = cvs[seg+1];
            d = cvs[seg+1];
        } else {
            a = cvs[seg-1];
            b = cvs[seg];
            c = cvs[seg+1];
            d = cvs[seg+2];
        }

        return curveFunction(a, b, c, d, v);
    }

    private static Vector3 curveFunction(Vector3 a, Vector3 b,
            Vector3 c, Vector3 d, float t) {
        float it = 1 - t;
        float t2 = t * t;
        float t3 = t2 * t;
        float b0 = it * it * it / 6;
        float b1 = (3 * t3 - 6 * t2 + 4) / 6;
        float b2 = (-3 * t3 + 3 * t2 + 3 * t + 1) / 6;
        float b3 = t3 / 6;
        return b0 * a + b1 * b + b2 * c + b3 * d;
    }
}
Code / Development / My Own Stuff April 11, 2012 @ 13:13

Python in French

# Pour Rudy, qui ne comprends pas un mot de Python quand c'est en Anglais.
import sys
dites = sys.stdout.write
ouvrez = open
lire = 'r'
ecrire = 'w'
fichier = 'd:/temp.txt'
texte_a_ecrire = u'Bonjour beau monde!'

dites('Je vais ouvrir un fichier qui s\'appelle %s\n' % fichier)
objet_fichier = ouvrez(fichier, ecrire)

# Traduire quelques fonctions
ecrivez = objet_fichier.write
fermez = objet_fichier.close

dites('Et maintenant, je vais ecrire cette texte dans le ficher: "%s"\n' % texte_a_ecrire)
ecrivez(texte_a_ecrire)
fermez()

dites('J\'ai ecrit et ferme le fichier, maintenant je vais ouvrir le meme ficher et dire ce qui se trouve de dedans.\n')

objet_fichier = ouvrez(fichier, lire)

# Encore plus des traductions
lisez = objet_fichier.read
fermez = objet_fichier.close

la_texte_dans_le_fichier = lisez()
dites('La texte dans le fichier: %s' % la_texte_dans_le_fichier)
fermez()

dites('Et voila, je disais tout que je vourdrais dire, merci!\n')
Music by me / My Own Stuff March 13, 2012 @ 00:53

Mountain Cast

For about 5 hours of fiddling and twisting, I was quite enchanted by what I’d be able to come up with. To be honest, I’ve been tweaking this one already a bit further than what you’re about to hear, but that’s for later. Maybe.

Music by me / My Own Stuff March 13, 2012 @ 00:48

Vintage: Red Dot Soundtrack

Here’s an oldie I just decided to put up here. Kinda liked it back then and it still sort of sticks with me.

Little story attached: We were at a nerdy computer party and beside the regular demo contests, they had an animation contest going on.

Pieter, Harm and I had fiddled around with 3D modelling/animation software for some time and I’d decided to put some work in mixing a couple of experiments together into what seemed to have become some sort of video-clip. Sound was needed, so I spent many hours in FastTracker (de-facto pc-music creation software for geeks back then) and this tune rolled out of it.

Anyhow, we entered the competition at the party and we got second place. But we got a lot of appreciation, which was really nice. So maybe it’s this that made me still remember the track and put it up here.

So, if you like it, cool! If not, well, you decided to come here! 😉

Code / Development / My Own Stuff May 14, 2011 @ 22:52

Ardor3D: Squad Interpolation

Just ported a spherical cubic (quadrangle) interpolation method to be used with Ardor3D‘s quaternions. I shamelessly ripped it, so I might as well share it:

    public static Quaternion lerp(Quaternion q1, Quaternion q2, double t,
            Quaternion store) {
        Quaternion c = Quaternion.fetchTempInstance();
        Quaternion d = Quaternion.fetchTempInstance();

        q1.multiply(1 - t, c);
        q2.multiply(t, d);

        q1.add(q2, store);
        store.normalizeLocal();

        Quaternion.releaseTempInstance(c);
        Quaternion.releaseTempInstance(d);

        return store;
    }

    public static Quaternion slerpNoInvert(Quaternion q1, Quaternion q2,
            double t, Quaternion store) {

        Quaternion c = Quaternion.fetchTempInstance();
        Quaternion d = Quaternion.fetchTempInstance();

        double dot = q1.dot(q2);

        if (dot > -0.95f && dot < 0.95f) {
            double angle = MathUtils.acos(dot);
            q1.multiply(MathUtils.sin(angle * (1 - t)), c);
            q2.multiply(MathUtils.sin(angle * t), d);
            c.add(d, store);

            divide(store, MathUtils.sin(angle), store);
            store.normalizeLocal();
        } else {
            lerp(q1, q2, t, store);
        }

        Quaternion.releaseTempInstance(c);
        Quaternion.releaseTempInstance(d);

        return store;
    }

    public static Quaternion divide(Quaternion a, double n, Quaternion store) {
        if (0 == n)
            throw new ArithmeticException("Divide by zero!");
        return store.set(store.getX() / n, store.getY() / n, store.getZ() / n,
                store.getW() / n);

    }

    public static Quaternion squad(Quaternion q1, Quaternion q2, Quaternion a,
            Quaternion b, double t, Quaternion store) {
        Quaternion c = Quaternion.fetchTempInstance();
        Quaternion d = Quaternion.fetchTempInstance();

        slerpNoInvert(q1, q2, t, c);

        slerpNoInvert(a, b, t, d);

        slerpNoInvert(c, d, 2 * t * (1 - t), store);

        Quaternion.releaseTempInstance(c);
        Quaternion.releaseTempInstance(d);

        return store;
    }

Will Perone, thanks!

EDIT: The previous version had a divide-by-zero problem, which should be fixed in the code above.

My Own Stuff / Pictures April 3, 2011 @ 23:18

Scooter Trip Pics

Two trips actually. One was to the north of Amsterdam, towards Marken. The other lead us to the Amsterdamse Waterleidingduinen (Amsterdam Waterworks Dunes), a nature area where much of our drinking water comes from and where fallow deers roam freely, which is rare in ‘City Park The Netherlands’. Definitely a place you might want to visit when you’re near and like to hike.

My Own Stuff / Personal / Pictures April 3, 2011 @ 23:06

Some More Tisse

Baby alert! Skip these pictures if you don’t like babies…

Read the rest of this entry…

Development / My Own Stuff January 23, 2011 @ 16:17

Find B-Spline Velocity/Tangent

As I’m not really good at maths, figuring this out took me a while; I wanted some code to let an object follow a long smooth path. But googling for hours didn’t give my any usable results.

One way to solve this, is to take two points on the curve and use the normalized difference to have a vector that is aligned to the curve. But this is imprecise and I wanted to do this properly.

Read the rest of this entry…

My Own Stuff / Personal / Pictures July 18, 2010 @ 21:21

Crazy Dutch People

Last week, the Dutch soccer team was welcomed back after losing the world cup final versus Spain in South Africa. Thousands of soccer fans travelled to Amsterdam to cheer at their hero’s. I took some pictures because they happened to pass through the canals, a couple of meters from my work.

Ok this starts looking like a crowd.
Whatever it takes
Danse la police!
One last big cheer at the team before they dissapear from view
Everybody tries to get a snapshot of the dutch soccer players emerging from under the bridge
Canal of people.
All this effort and he didn't even catch a glimpse of the soccer players because he took a wrong turn (or was too late).
Don't fall asleep now

See the whole album here.

My Own Stuff / Personal / Pictures July 1, 2010 @ 21:28

Groetjes from Festival Mundial

Couple of snapshots I took during Festival Mundial
